QSK60-C

Model: QSK60-C
ECM: CM500, CM2150
Fuel Systme: HPI, MCRS
Rated Power: 2,237 BHP - 3,000 BHP
Typical Applications: BelAZ 75306, 75313, Komatsu 830E

INQUIRY

Product Details

Product Tags

Model	QSK60-C (2237)	QSK60-C (2300)	QSK60-C (2500)	QSK60-C (1875)
Rated Power	1,668 KW @ 1800 RPM	1,715 KW @ 1900 RPM	1,864 KW @ 1900 RPM	1,398 KW @ 1800 RPM
Peak Torque	9,053 N-m @ 1500 RPM	9,053 N-m @ 1500 RPM	9,839 N-m @ 1500 RPM	8,364 N-m @ 1500 RPM
CPL	2821	2849	2849	3451
Configuration	D593001CX03	D593001CX03	D593001CX03	D593007CX03
Fuel System	HPI	HPI	HPI	MCRS
ECM Version	CM500	CM500	CM500	CM2150
Application	BelAZ 75306	BelAZ 75306 200T	BelAZ 75313	Komatsu PC4000
Emission Certification	Non-certified	U.S. EPA Tier 1	U.S. EPA Tier 1	U.S. EPA Tier 2
Aspiration	Turbocharged and Aftercooled	Turbocharged and Aftercooled	Turbocharged and Aftercooled	Turbocharged and Aftercooled
Displacement	60L	60L	60L	60L
No. of Cylinders	16	16	16	16
Compression Rate	14.5:1	14.5:1	14.5:1	14.5:1
Bore & Stroke	159mm X 190 mm	159mm X 190 mm	159mm X 190 mm	159mm X 190 mm
Fuel Consumption	202 g/KW-hr @ 1800 RPM	208 g/KW-hr @ 1900 RPM	206 g/KW-hr @ 1900 RPM	211 g/KW-hr @ 1800 RPM
Cooling System Type	2 Pump 2 Loop	2 Pump 2 Loop	2 Pump 2 Loop	2 Pump 2 Loop

As you might know, the QSK60-C CM500 (HPI) model is no longer available. There are a few alternatives to address this problem. One of the solutions is to modify a QSK60-G engine into a QSK60-C, by adding accessories such as fan clutch, Elimination filter, air compressor on to the engine. We have sold quite a few such units to the end users, and they work.

However, those QSK60-G engines are with different camshaft, injectors, and turbochargers. Some might worry that they would not last. In the light of that, we have another perfect solution just for you. We will use a QSK60 CM2150 MCRS engine from the oil & gas application and modify it into a mining engine. Both an oil & gas engine and a mining engine are made for industrial applications, unlike the power generation engines, which are used at a fixed RPM.

The QSK60 CM2150 MCRS are slightly different from the QSK60 CM500. It has a different control system and fuel system. Fortunately with just some minor modifications on the wiring, it will fit perfectly into your dump truck. Our application engineering team, with support from Cummins, will be able to make that change for you without any concern.
